MAHA BAT

PRODUCTS FEATURES

Battery Type	Nominal Voltage	Nominal Capacity (Ah)		Dimentions (mm)				Weight (±5%)
		10HR	5HR	Dimentions (mm)				Weight (±5%)
		Final Voltage V.P.C.(1.80)	Final Voltage V.P.C.(1.70)	Length	Width	Height	T.Height	(APPROX.)
PNB 1272	12	7.2	6.6	151	65	95	100	2.3
PNB 12120	12	12.0	11.0	151	98	95	100	3.6
PNB 12180	12	18.0	16.6	180	75	167	167	5.4
PNB 12210	12	21.0	19.3	192	116	144	144	7.8
PNB 12240	12	24.0	22.1	165	175	126	126	8.1
PNB 12280	12	28.0	25.8	165	125	180	180	10.5
PNB 12340	12	34.0	31.3	196	130	168	168	10.8

Battery Type	Nominal Voltage	Nominal Capacity (Ah)		Dimentions (mm)				Weight (±5%)
		10HR	5HR	Dimentions (mm)				Weight (±5%)
		Final Voltage V.P.C.(1.80)	Final Voltage V.P.C.(1.70)	Length	Width	Height	T.Height	(APPROX.)
PNB 12400	12	42	40	197	166	170	170	13.0
PNB 12650	12	68	65	325	166	175	175	21.0
PNB 12700	12	75	70	350	166	175	175	23.5
PNB 12800	12	80	74	350	166	175	175	24.0
PNB 121000H	12	100	92	330	174	215	239	29.0
PNB 121000S	12	100	92	443	167	204	228	35.0
PNB 121200H	12	120	110	332	174	215	239	32.0
PNB 121300S	12	130	118	443	167	204	228	40.0
PNB 121500	12	150	140	500	260	196	225	49.0
PNB 122000	12	200	189	500	260	196	225	59.0
PNB 122200	12	220	200	500	260	196	225	62.0
